Naim Audio Supernait 2 Integrated Amplifier

Naim SUPERNAIT Integrated Amplifier

• 80W per channel (in 8 ohms), 130W per channgel (into 4 ohms)
• Built in Naim DR (Discrete Regulator) supplying preamplifier section
• ¼″ (6.35mm) headphone output and high-quality Class-A headphone amplifier
• Constant current source circuit technique employed (introduced in NAC 552 preamplifier) to provide ultra-quiet drive signals for relays to improve sound quality
• All inputs are individually decoupled and hand-wired for improved microphonic isolation (as per NAC 282 upwards)
• Ceramic heat sink isolation for improved sound quality on power and preamp section
• Performance upgradable via Naim FlatCap, HiCap or SuperCap power supplies
• Powered input for use with StageLine or SuperLine phono stages
• USB-mini B for future software upgrades
• British build and design

Technical highlights include a Class A preamp output stage which doubles as a headphone amplifier, ceramic heatsink technology that minimises capacitive coupling between the chassis and output transistors and individually decoupled and hand-wired input sockets. Its internal switching employs ultra-low-noise, constant current sources which are derived directly from the flagship NAC 552 preamplifier. The SUPERNAIT 2 doesn't miss a trick or a beat.

It doesn't miss any music either. The SUPERNAIT 2 is never fazed by the demands of either speaker or music. It simply delivers dynamic, detailed and engaging music that can’t fail to move you.

AUDIO INPUTS
Input Level	Suitable for 2V sources (0.5 to 5.0V)
Input Sensitivity	130mV
Analogue Inputs	4 x DIN/RCA pair, 1 x RCA pair, 1 x DIN (for Naim phono amplifier)
USER CONTROL INTERFACE
Front Panel	Volume control, balance control and front panel buttons
AUDIO OUTPUTS
Line Outputs Fixed (level)	AV (DIN), HDD (DIN) 130mV, 600Ω
Line Outputs Variable (level)	Pre-amp (DIN), bi-amp (DIN), sub (RCA pair) 775mV, <50Ω
Power Output	+24V for Naim phono amplifier
Headphone outputs	¼ inch (6.35mm) TRS Socket
SPEAKER OUTPUTS
Power Output	80W per channel into 8Ω, 130W per channel into 4Ω
UPGRADES
Power Supply	FlatCap, HiCap or SuperCap
CONNECTIVITY
Remote Control	Infra-Red (RC5)
Remote Input	1 x 3.5mm jack on rear
Updates	1 x USB mini-B
POWER
Mains Supply	100V, 115V, 230V; 50 or 60Hz
Power Consumption (quiescent)	37VA
Power Consumption (maximum)	400VA
PHYSICAL
Dimensions	87 x 432 x 314 (H x W x D)
Weight	13.4kg
Supplied With	NARCOM-4 remote control
OTHER
Suggested System	CDX2 CD player or NDX network player
FINISH
Front	Brushed and black anodised aluminium
Case	Black powder coated aluminium
